Heschen Photoelectric Switch E3JM-R4M4 DC/AC 12-240V 3A 250VAC 30VDC, Diffuse Type Detection Distance 4m


  • €18,79
    Unit price per
Shipping calculated at checkout.

  • supply voltage: 24-240V AC,12-240V DC, Output: 3A 250V AC,30V DC
  • Detection method: diffuse type
  • Relay output: DC illuminate
  • Detection target: Transparent/Opaque object
  • Detection range: 4m
  • respnose time: 30ms
  • Light source: Infrared light 660nm
  • Impulsion and vibration are allowed: B<30g,T<11ms, f<55Hz, a<1mm
  • Insulation impedance: 50Mohm above between charging part and housing
  • Withstand voltage: AC1000V 50/60Hz 1min between charging part and housing
  • protection structure: IP65
  • Material: Housing: Nickel plated brass(ABS) Detection surface(lens): PMMA
